Utah · Engineer seal requirements
Utah PE seal requirements: size, wording, and the rule that sets them
As of
Utah's seal rule is R156-22-601. The seal is circular and 1-1/2 inches minimum diameter, and it carries the licensee's name, license number, "State of Utah", and, as appropriate, "Professional Engineer", "Professional Structural Engineer" or "Professional Land Surveyor". Utah issues a separate professional structural engineer license, and that license has its own legend. The signature and the date must appear across the face of each seal imprint, not beside it.
R156-22-601 states a minimum diameter and nothing else; the "maximum 2 inches" figure circulated for Utah is in no part of the rule. The agency is now the Division of Professional Licensing (DOPL); the older name Division of Occupational and Professional Licensing survives only in the legacy heading of the R156 code title.
Utah Engineer seal
- Legend (any one)
- “Professional Engineer” · “Professional Structural Engineer”
- Diameter
- Circular, 1-1/2 inches minimum diameter. The rule states no maximum.
- Expiration date
- The seal carries the licensee's name, license number, "State of Utah" and the legend. Utah prescribes no artwork and no license date.(R156-22-601(1)(b))
- Signature date
- The signature and date must appear across the face of each seal imprint, not beside it; the cover or title sheet carries the original imprint, signature and date.(R156-22-601(1)(c)-(d))
- City on seal
- The rule does not require a city on the seal.(R156-22-601(1)(b))
- Each seal includes the licensee's name, license number, "State of Utah", and, as appropriate, "Professional Engineer", "Professional Structural Engineer", or "Professional Land Surveyor".(R156-22-601(1)(b))
- Each seal is signed and dated with the signature and date appearing across the face of each seal imprint.(R156-22-601(1)(c))
- Each original set of final plans, specifications, reports, maps, sketches, surveys, drawings, documents and plats has, at a minimum, the original seal imprint, original signature and date on the cover or title sheet.(R156-22-601(1)(d))
- A seal may be a wet stamp, embossed, or electronically produced, and electronically generated signatures are acceptable.(R156-22-601(1)(e)-(f))
- It is the responsibility of the licensee to provide adequate security when documents with electronic seals and electronic signatures are submitted. The rule prescribes no certificate technology and names no signature statute.(R156-22-601(1)(g))
- Sheets subsequent to the cover of specifications are not required to be sealed, signed and dated.(R156-22-601(1)(g))
- Copies of the original set are permitted if the seal, signature and date are clearly recognizable.(R156-22-601(1)(h))
- A person who qualifies for and uses the title of professional engineer intern is not permitted to use a seal.(R156-22-601(2))
- Utah Code § 58-22-601 requires the seal but delegates its design and implementation entirely to the division by rule, so R156-22-601 is the whole of the specification and no artwork is prescribed.(Utah Code § 58-22-601)
Utah engineer seal questions
Is there a maximum diameter for a Utah PE seal?▾
1-1/2 inches is a floor, not a range. The rule states a minimum diameter and no maximum, so the "minimum 1½ inches, maximum 2 inches" pairing quoted for Utah has no source in R156-22-601. (R156-22-601(1)(a))
Can the signature and date sit next to a Utah PE seal instead of across it?▾
The signature and date go across the face of the seal imprint. Placing them next to the seal, or putting the date in the title block, does not meet the rule. (R156-22-601(1)(c))
Can a Utah PE use the "Professional Structural Engineer" seal legend?▾
"Professional Structural Engineer" is a separate Utah legend for a separate license. A licensee holding only the professional engineer license uses "Professional Engineer" even on structural work. (R156-22-601(1)(b))
Can a professional engineer intern in Utah use a seal?▾
A professional engineer intern may not use a seal at all. (R156-22-601(2))
Generate a Utah Engineer seal to this specification
Board approved
Your Utah Professional Engineer seal from pedigitalstamps.com meets every requirement on this page — the required wording, the layout and the diameter set out in Utah Admin. Code R156-22-601 (Seal Requirements). Fill in your details and download it in seconds.
Every format you need is included — PNG, PDF, SVG and CAD — ready to place in Bluebeam, Acrobat or AutoCAD.
