Tennessee · Engineer seal requirements
Tennessee PE seal requirements: size, wording, and the rule that sets them
As of
Tennessee prescribes the engineer's seal by picture. Rule 0120-02-.08(1)(a) reproduces the required design — the registrant's name arcing the top of the outer band, "REGISTERED ENGINEER" on the inner band, the Great Seal of Tennessee in the center, "No." for the license number, and "STATE OF TENNESSEE" along the bottom — and gives no dimension at all. The legend is "REGISTERED ENGINEER", not "Professional Engineer". Land surveyors fall under a different board and a different rule, 0820-04-.08, which fixes their seal at two inches in diameter in all cases.
The 1⅝-to-1⅞-inch range quoted for Tennessee has no source in the rules: the words "inch", "diameter" and "size" appear nowhere in chapters 0120-01 or 0120-02. The two-inch figure belongs to the land surveyor rule. The Secretary of State still publishes the rule-maker as the State Board of Architectural and Engineering Examiners (Title 0120), while the board's own page uses the name State Board of Examiners for Architects, Engineers, and Land Surveyors.
Tennessee Engineer seal
- Seal rule
- Rule 0120-02-.08 (Seals)
- Legend
- “REGISTERED ENGINEER”
- Diameter
- The rule prescribes the seal by illustration and states no diameter. Neither chapter 0120-01 nor chapter 0120-02 mentions inches or diameter.
- Expiration date
- The prescribed illustration carries the registrant's name, "REGISTERED ENGINEER", the Great Seal of Tennessee, "No." for the license number and "STATE OF TENNESSEE". No license date of any kind appears on it.(Rule 0120-02-.08(1)(a))
- Signature date
- The registrant superimposes the signature and the date of signature across the face and beyond the circumference of the seal. The seal graphic itself must not contain either.(Rule 0120-02-.08(3), (8)(a))
- City on seal
- The rule does not require a city on the seal.(Rule 0120-02-.08(1)(a))
- The design is fixed by the illustration at 0120-02-.08(1)(a): the registrant's name arcing the top of the outer band, "REGISTERED ENGINEER" on the inner band, the Great Seal of Tennessee device in the center, "No." for the license number below it, and "STATE OF TENNESSEE" arcing the bottom.(Rule 0120-02-.08(1)(a))
- "STATE OF TENNESSEE" sits on the bottom arc. The registrant's name is what runs across the top.(Rule 0120-02-.08(1)(a))
- The registrant shall superimpose his signature — not a rubber stamp — and the date of signature across the face and beyond the circumference of the seal.(Rule 0120-02-.08(3))
- Rubber-stamp, embossed, transparent self-adhesive or electronically generated seals may be used. Such stamps or seals shall not include the registrant's signature or date of signature.(Rule 0120-02-.08(8)(a))
- An electronically generated signature and date are placed either across the face and beyond the circumference of the seal or adjacent to it. A digital signature must be unique to the individual, capable of verification, under sole control, and linked so that it is invalidated if any data in the document is changed.(Rule 0120-02-.08(8)(b))
- The registrant stamps all original sheets of any bound or unbound set of working drawings or plans, the original cover or index page identifying all specification pages covered, and the original cover or index page for design calculations or reports submitted for review.(Rule 0120-02-.08(2))
Tennessee engineer seal questions
Does a Tennessee engineer's seal say "Professional Engineer"?▾
The engineer legend is "REGISTERED ENGINEER". Neither "Professional Engineer" nor "P.E." appears anywhere in the rule. (Rule 0120-02-.08(1)(a))
Where does "STATE OF TENNESSEE" go on a Tennessee engineer's seal?▾
"STATE OF TENNESSEE" belongs on the bottom arc, with the registrant's name across the top. Templates built for other states usually have these reversed. (Rule 0120-02-.08(1)(a))
Can a Tennessee engineer's seal image include the signature and date?▾
The seal graphic itself must not contain the signature or the date. Both are applied separately, across the face and beyond the circumference of the seal. (Rule 0120-02-.08(3), (8)(a))
Does a Tennessee engineer's seal have to be 2 inches in diameter?▾
The two-inch requirement people cite for Tennessee is the land surveyor rule. Engineers and architects have no prescribed diameter at all. (Rule 0820-04-.08(2))
