Pennsylvania · Engineer seal requirements
Pennsylvania PE seal requirements: size, wording, and the rule that sets them
As of
Pennsylvania fixes one diameter rather than a range. 49 Pa. Code § 37.58 requires a 1¾-inch seal in the identical design authorized by the Board, carrying the legend "Registered Professional Engineer", your name and registration number, and a reference to the Commonwealth of Pennsylvania. A pocket seal may be reduced to 1½ inches only if the design keeps the same relative proportions. A digital seal is an electronic image carrying those same elements.
Pennsylvania prescribes one diameter rather than a range, and allows a smaller pocket seal only if the proportions are kept.
Pennsylvania Engineer seal
- Legend
- “Registered Professional Engineer”
- Diameter
- 1¾ inches in diameter. A pocket seal may be reduced to 1½ inches provided the design keeps the same relative proportions.
- Expiration date
- The seal carries the legend "Registered Professional Engineer", the registrant's name and registration number, and a reference to the Commonwealth. § 37.59(5) bars sealing after licensure expires, but no expiration date goes on or beside the seal.(49 Pa. Code § 37.58(b); § 37.59(5))
- Signature date
- On final or complete documents the seal, the signature and the date of issuance are prominently displayed on the first page.(49 Pa. Code § 37.59(2))
- City on seal
- The rule lists the legend, the name, the registration number and the Commonwealth reference, and forbids a self-designed seal (§ 37.58(a)).(49 Pa. Code § 37.58(b))
- The seal is in the identical design authorized by the Board, and you obtain it at your own expense.(49 Pa. Code § 37.58)
- It carries the legend "Registered Professional Engineer", your name and registration number, and a reference to the Commonwealth of Pennsylvania.(49 Pa. Code § 37.58)
- A digital seal is an electronic image carrying the same elements — name, license number, the "Registered Professional Engineer" legend and the reference to the Commonwealth.(49 Pa. Code § 37.58)
Pennsylvania engineer seal questions
Is a Pennsylvania PE seal 1⅝ inches in diameter?▾
1⅝ inches is not a permitted Pennsylvania size, though it is widely quoted. The rule gives 1¾ inches, with 1½ inches allowed only for a proportionally reduced pocket seal. (49 Pa. Code § 37.58)
Can a Pennsylvania PE seal use "P.E." as the legend?▾
"P.E." is not the Pennsylvania legend. The rule requires "Registered Professional Engineer". (49 Pa. Code § 37.58)
Can I design my own layout for a Pennsylvania engineer seal?▾
Pennsylvania does not let you design your own layout — the seal has to be the design the Board authorized. (49 Pa. Code § 37.58(a))
Where does a Pennsylvania PE put the seal, signature and date on a document?▾
The signature is applied near or across the seal but must not obliterate the registration number, and the seal, signature and date of issuance all belong on the first page. (49 Pa. Code § 37.59)
