Maine · Engineer seal requirements
Maine PE seal requirements: size, wording, and the rule that sets them
As of
Maine's engineer seal is 1-3/4 inches in diameter, the format the Board designates Size #1. The legend is fixed by statute at 32 M.R.S. §1355 as "licensed professional engineer", and the Board's approved format adds the licensee's name, the license number and the indication "State of Maine" — with no position prescribed for it and lettering in ALL CAPS so the seal stays clear after image transfer. The diameter comes from the Board's approved format rather than from the rule text, which authorizes "a seal of the size and design prescribed by the Board". Engineers, architects and land surveyors each answer to a different Maine board.
Sources that call Maine's seal size unregulated are reading only 02-322 C.M.R. Ch. 2 §9, which delegates size and design to the Board rather than stating a number. The Board then prescribes 1-3/4 inches on its Approved Seal Format page. No architect entry appears below: 32 M.R.S. §225 leaves the architect's seal design entirely to the architects' board, and that board publishes no seal-design specification, so the "Licensed Architect" seal sold by vendors has no primary source behind it.
Maine Engineer seal
- Legend
- “Licensed Professional Engineer”
- Diameter
- 1-3/4 inches in diameter, the format the Board designates Size #1.
- Expiration date
- The Board's approved format lists the name, the license number, "Licensed Professional Engineer" and "State of Maine" — no date. The statute bars sealing after the license expires, but puts no expiry date on the seal.(Board Approved Seal Format, under 02-322 C.M.R. Ch. 2 §9(1); 32 M.R.S. §1355)
- Signature date
- "The Licensee's signature and the date must accompany the seal." A seal is applied, signed and dated on every category of document listed in §9(5). An electronic signature under 10 M.R.S.A. §9402 is effective.(02-322 C.M.R. Ch. 2 §9(3) and §9(5))
- City on seal
- The rule does not require a city on the seal.(Board Approved Seal Format; 02-322 C.M.R. Ch. 2 §9)
- The seal must include the licensee's name, license number and "Licensed Professional Engineer".(Board Approved Seal Format; 32 M.R.S. §1355)
- The seal must include the indication "State of Maine". The Board prescribes no position for it.(Board Approved Seal Format)
- Lettering should be in ALL CAPS, so the seal remains clear even after image transfer.(Board Approved Seal Format)
- The license number may be preceded by any designation likely to indicate to an observer that it is the license number — PE00000, License Number 00000, Lic. 00000, No. 00000, #00000 — but since license numbers are the only numbers on the seal, no designation is required.(Board Approved Seal Format)
- The seal may be an embossed seal, a rubber stamp or an electronically generated image.(02-322 C.M.R. Ch. 2 §9(1))
- The licensee's signature and the date must accompany the seal. An electronic signature as defined by 10 M.R.S.A. §9402 is effective.(02-322 C.M.R. Ch. 2 §9(3))
- Sealed documents may be transmitted electronically.(02-322 C.M.R. Ch. 2 §9(4))
- A seal is applied, signed and dated on all professional engineering plans, specifications, reports or calculations prepared under the responsible licensee's direction, formally filed with any public body or agency, or submitted to contractors for bids or estimates or released for construction.(02-322 C.M.R. Ch. 2 §9(5))
- CAD and other electronic deliverables released without a seal must carry: "This document was originally issued and sealed by (Licensee Name, PE License #), on (Date of original sealing)".(02-322 C.M.R. Ch. 2 §9(6))
- Sealing the first sheet of a bound set suffices if the intent is to cover the entire document; otherwise the first sheet must state the number of sheets covered by each licensee's seal.(02-322 C.M.R. Ch. 2 §9(9))
Maine engineer seal questions
Should a Maine PE seal say "P.E." or "Licensed Professional Engineer"?▾
"P.E." is not the Maine legend. The statute fixes it as "licensed professional engineer". (32 M.R.S. §1355)
Is there a required size for a Maine PE seal?▾
The size is prescribed even though the rule contains no number. 02-322 C.M.R. Ch. 2 §9(1) delegates to the Board, and the Board's approved format is 1-3/4 inches, known as Size #1. (Board Approved Seal Format; 02-322 C.M.R. Ch. 2 §9(1))
Does "State of Maine" have to go at the top of a Maine PE seal?▾
Nothing requires "State of Maine" at the top. The Board requires only that the seal include the indication; it prescribes no position. (Board Approved Seal Format)
Does a Maine PE seal need a signature and date, and can the signature be electronic?▾
The licensee's signature and the date must accompany the seal. An electronic signature as defined by 10 M.R.S.A. §9402 is effective for this purpose. (02-322 C.M.R. Ch. 2 §9(3))
