Arizona · Land Surveyor seal requirements
Arizona Land Surveyor seal requirements: size, wording, and the rule that sets them
As of
Land surveyors in Arizona seal under A.A.C. R4-30-303 (Securing Seals) and Appendix A (Sample Seals), administered by the Arizona State Board of Technical Registration. The seal reads “Registered Land Surveyor”. 1 1/2 inches in diameter, the same seal specification as every other registrant.
R4-30-304 is often cited as the Arizona seal rule; it governs where the seal goes on documents. What the seal must contain, and its size, are in R4-30-303 and Appendix A. Both were last amended by final rulemaking at 24 A.A.R. 1785, effective August 5, 2018.
Arizona Land Surveyor seal
- Legend
- “Registered Land Surveyor”
- Diameter
- 1 1/2 inches in diameter, the same seal specification as every other registrant.
- Expiration date
- No. R4-30-304(E) requires only an original or computer-generated seal matching the one on file with the Board, a signature that does not obscure the printed name or registration number, and the date the document was sealed. A former subsection did require an expiration notation beneath the seal, but it and its Appendix B were repealed in 2018 — sources still showing it are quoting the 2008-2018 text.(A.A.C. R4-30-304(E) (Supp. 24-1); former R4-30-304(E)(4) and Appendix B repealed by 24 A.A.R. 1785, effective August 5, 2018)
- Signature date
- R4-30-304 applies to every registrant of the Board: sign, date and seal, with the date the document was sealed on the original.(A.A.C. R4-30-304(D), (E)(3))
- City on seal
- "Arizona U.S.A." is the only place inscription.(A.A.C. R4-30-303(A)(2))
- The phrase in the upper annular space is "Registered Land Surveyor" — not "Professional Land Surveyor", and with no branch to name.(R4-30-303(A)(1))
- "Arizona U.S.A." at the bottom of the annular space, and the registrant's name, registration number and the words "date signed" in the inner circle.(R4-30-303(A)(2))
Arizona land surveyor seal questions
Does an Arizona land surveyor's seal say "Professional Land Surveyor"?▾
No. The phrase the rule assigns to the upper annular space is "Registered Land Surveyor" — Arizona never took the "Professional Land Surveyor" wording most states use on the seal. Nothing is appended to it either: an engineer must name the branch of engineering after the profession phrase, but the surveyor's phrase stands alone. (A.A.C. R4-30-303(A)(1))
Which sheets of an Arizona survey carry the land surveyor's seal?▾
Every map sheet, and the master sheets on top of that. The rule requires a permanently legible imprint of the seal and the signature on each sheet of drawings or maps, and again on each of the master sheets when they are reproduced into a single set of finished drawings or maps. The cover-or-index shortcut in the same rule is written for specifications, addenda, bound details and reports, not for maps. (A.A.C. R4-30-304(A)(1)-(2))
Is there an official Arizona sample seal for land surveyors?▾
There is not, even though the rule requires a seal "identical in style, size, and appearance to the sample shown in Appendix A". Appendix A prints its samples for the Registered Professional Engineer, the Registered Geologist, the Registered Landscape Architect and the Registered Assayer, and none for a land surveyor. What it does supply is the geometry — a 1 1/2" ± 1/16" outer circle and a 1 1/8" ± 1/16" inner circle — the "CERTIFICATE NO." and "Date Signed" furniture, the "ARIZONA, U.S.A." inscription, and the instruction "Sign your name across lower portion of the seal. Do not cover your name or registration number with your signature." (A.A.C. R4-30-303(A); Appendix A (Sample Seals), Supp. 24-1)
