Connecticut Land Surveyor seal requirements: size, wording, and the rule that sets them
As of
Land surveyors in Connecticut seal under RCSA § 20-300-10 (License seals and stamps), with the design and size prescribed by the Board, administered by the State Board of Examiners for Professional Engineers and Land Surveyors. The seal reads “LICENSED LAND SURVEYOR”. 1½ inches in diameter, as prescribed by the Board — the same as the engineer's seal.
The 1¼-to-2-inch range often quoted for Connecticut appears in no Connecticut authority. The Board prescribes a single diameter, 1½ inches. CGS § 20-304 is only the enabling authority for seal regulations, and CGS § 20-302 is "Requirements for licensure" — neither describes the seal.
Connecticut Land Surveyor seal
- Seal rule
- RCSA § 20-300-10 (License seals and stamps), with the design and size prescribed by the Board
- Legend
- “LICENSED LAND SURVEYOR”
- Diameter
- 1½ inches in diameter, as prescribed by the Board — the same as the engineer's seal.
- Expiration date
- The surveyor specimen is the engineer's design with "LICENSED LAND SURVEYOR" in the bottom arc — no date.(Board seal specification (12 July 2022), under RCSA § 20-300-10(a))
- Signature date
- § 20-306a covers land surveying papers and documents on the same terms as engineering ones.(CGS § 20-306a(a))
- City on seal
- The rule does not require a city on the seal.(Board seal specification (12 July 2022), under RCSA § 20-300-10(a))
- The surveyor specimen is the engineer's design with "LAND SURVEYOR" in the bottom arc: "STATE OF CONNECTICUT" at the top, the name, the state coat of arms, the license number, then "LICENSED" over "LAND SURVEYOR".(Board seal specification (12 July 2022))
- A licensed land surveyor must indicate on any map or survey bearing the seal and signature that it is substantially correct to the degree of accuracy shown, classified under RCSA § 20-300b-11.(RCSA § 20-300-10(f))
Connecticut land surveyor seal questions
Can a Connecticut PE and land surveyor use one combined seal?▾
No. RCSA § 20-300-10(b) is explicit: "Where a licensee is classified as a professional engineer and as a land surveyor, two seals are necessary." A single seal naming both classifications is not an option in Connecticut, however convenient it is for someone who signs in both capacities. (RCSA § 20-300-10(b))
Does a Connecticut land surveyor seal say "Professional Land Surveyor"?▾
No. The Board-prescribed design puts the word "LICENSED" above "LAND SURVEYOR" in the bottom arc — "Professional", the word most other states use, appears nowhere on it. "Licensed" is not decorative either: the Board's specification records that P.A. 82-61, 82-317 and 82-370 changed the registration process for engineers and land surveyors into a licensing process, and that every license issued after July 1, 1982 requires the licensee to use a seal containing that word. (Board seal specification (12 July 2022), under RCSA § 20-300-10(a))
Can a Connecticut land surveyor seal work prepared by someone else?▾
Yes, on a condition that has to be met before the seal goes on. RCSA § 20-300-10(b) first bars a licensee from sealing anything not prepared personally or under their supervisory control, then permits sealing documents prepared by others where the licensee prepares — and retains for not less than six years — a thorough written evaluation of the professional services the documents represent, covering drawings, specifications, reports, design calculations and the applicable codes and standards, and identifying the project, the documents, their source, who the evaluation was done for and its date. The licensee's seal and signature go on that evaluation too. (RCSA § 20-300-10(b))
Who carries the risk if someone else uses a Connecticut land surveyor's seal?▾
The licensee does, until the loss is reported. RCSA § 20-300-10(g) requires a licensee whose seal is lost to report it to the board of examiners and the Department of Consumer Protection immediately, and in no case later than fifteen days after discovery. Until that report is made, misuse of the seal by anyone else remains the licensee's own responsibility, and failing to report can itself draw discipline. A petition for the issuance of a new license may be submitted at the same time as the report. (RCSA § 20-300-10(g))
