Illinois · Engineer seal requirements
Illinois PE seal requirements: size, wording, and the rule that sets them
As of
Illinois puts the state inside the legend. Under 68 Ill. Adm. Code § 1380.295 the seal carries your name, your license number and the words "Licensed Professional Engineer of Illinois", and no diameter is prescribed. A reproducible seal or facsimile is permitted and may be computer generated. Illinois then asks for something most states do not: your license expiration date has to appear adjacent to the seal, alongside your signature and the date of signing.
Illinois licenses structural engineers under a separate Act with its own seal rule (68 Ill. Adm. Code 1480.145); a structural engineer's seal is not the PE seal below. Note also that the license expiration date has to sit next to the seal — a detail that catches out-of-state filers.
Illinois Engineer seal
- Legend
- “Licensed Professional Engineer of Illinois”
- Diameter
- The rule does not prescribe a diameter. Illustration A in the Part shows a suggested facsimile but gives no dimensions.
- Expiration date
- Beside the seal, not inside it: the written signature, the date of signing and the date of license expiration all go adjacent to the seal.(68 Ill. Adm. Code § 1380.295(a))
- Signature date
- The date of signing goes adjacent to the seal, with the signature and the expiration date.(68 Ill. Adm. Code § 1380.295(a))
- City on seal
- The impression carries the name, the license number and the words "Licensed Professional Engineer of Illinois". A place of business is required on the land surveyor's seal, not the engineer's.(68 Ill. Adm. Code § 1380.295(a))
- The seal carries your name, your license number, and the words "Licensed Professional Engineer of Illinois" — the state is part of the legend itself, not a separate band.(68 Ill. Adm. Code § 1380.295(a))
- Your written signature, the date of signing and your license expiration date must all appear adjacent to the seal.(68 Ill. Adm. Code § 1380.295)
- A reproducible seal or facsimile is permitted and may be computer generated.(68 Ill. Adm. Code § 1380.295)
- The signature may be an original in your handwriting, a scanned copy of a document bearing an original signature, or computer generated.(68 Ill. Adm. Code § 1380.295)
- A document bearing the name of a professional design firm instead of the individual licensed engineer responsible for it is deemed an invalid seal.(68 Ill. Adm. Code § 1380.295)
Illinois engineer seal questions
Does an Illinois PE seal need the license expiration date next to it?▾
The license expiration date must sit next to the seal. A seal accompanied only by a signature and a date is incomplete in Illinois. (68 Ill. Adm. Code § 1380.295)
Can an Illinois document be sealed in the design firm's name instead of the engineer's?▾
A document bearing the name of a professional design firm instead of the individual engineer responsible for it is deemed an invalid seal. (68 Ill. Adm. Code § 1380.295)
Is an Illinois structural engineer's seal the same as the PE seal?▾
Structural engineers are licensed under a separate Act with its own seal rule at 68 Ill. Adm. Code § 1480.145. A structural engineer's seal is not the PE seal.
